Wood Ovo M/O 1g 13A DP Swt Skt PB/BL

SKU: WOMSS1PBB Category:
Wood Ovo M/O 1g 13A DP Swt Skt PB/BL
Wood Ovo M/O 1g 13A DP Swt Skt PB/BL - Image 2
Wood Ovo M/O 1g 13A DP Swt Skt PB/BL - Image 3
Wood Ovo M/O 1g 13A DP Swt Skt PB/BL - Image 4
SKU: WOMSS1PBB Category:

Type

1 gang 13A Double Pole Switched Socket

Plate Finish

Medium Oak

Insert Finish

Polished Brass/Black

Description

Woods Ovolo Medium Oak 1 gang 13A Double Pole Switched Socket Polished Brass/Black

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Woods
Page-Sort-Order

030-021-001
Insert-Type

1 gang 13A Double Pole Switched Socket
Insert-Colour

Polished Brass/Black
Uf-ItmLabelTechInsert

SS1
Uf-HAM-Plate-Range

Woods Ovolo
Uf-HAMPlate-Generic-Size

Single
Range-Name

Woods
Item-Long-Description

Woods Ovolo Medium Oak 1 gang 13A Double Pole Switched Socket Polished Brass/Black
PlateFinish

Woods Ovolo Medium Oak
EAN13-Barcode

5017504322014
Dimensions(Nominal)

Single: Height = 88.0mm Width = 88.0mm Depth = 13.5mm
Switched-Poles

Double
Current-Rating

13 Amp
Maximum-Load

13 Amp
Mains-Frequency

50Hz
Contact-Gap-Minimum

3mm
Terminal-Capacity-1

4×2.5mm²
Terminal-Capacity-2

3x4mm²
Terminal-Capacity-3

2x6mm² Multi-Strand
Terminal-Capacity-4

1x10mm²
Earth-Terminal-Capacity-1

4×2.5mm²
Earth-Terminal-Capacity-2

3x4mm²
Earth-Terminal-Capacity-3

2x6mm² Multi-Strand
Earth-Terminal-Capacity-4

1x10mm²
Product-Class-1

Must be earthed
Ambient-Operating-Temperatur

-5° to +40°C
Recommended-Location

Internal Use Only
Maximum-Installation-Altitud

2000m
Standard-Approval

BS 1363-2
Commodity-Code

85366990
Wiring-Image

Item-Image

Dimension-Image

Luckins-TSI

391603763
Tech-Sheet-Page-Footer

WOMSS1PB-B – Woods Ovolo Medium Oak 1 gang 13A Double Pole Switched Socket Polished Brass/Black
product-code

S WD OV-MO
family-code

S WOODS
last-inv

02/04/2025
unit-weight

86.00000
weight-units

GR
Uf-LuckinsEDP

4533221242
Uf-HAMInnerBoxQty

1
Uf-OuterBoxQty

24
Picture-Exists

Yes
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

30
HAM-SortOrder

21
InsertSortOrder

001
Generic-Size

Single
Box-Fixing-Hole-Centres

60.3mm
Grid-Fixing-Hole-Centres

N/A
Uf-HAMPlateFinish

Medium Oak
Uf-HAMFrameFinish

n/a
WEB-InsertType

Switched Socket
WEB-NumberofGangs

1
MainInsertColour

Polished Brass
TrimColour

Black
Last-Updated-At-Hamilton

23/01/2026
WoodEdge

Ovolo
Fixing-Hole-Centres

Box Fixing = 60.3mm Grid Fixing = N/A
Minimum-Wall-Box-Depth

35mm
Plate-Finish

Medium Oak
Subheader2

Woods Power Sockets
QR-Instruction

https://online.fliphtml5.com/Hamilton/dcop/#p=1
Weight

86 GR
Voltage

220/250V AC
IP-Rating

IP2XD
description

Wood Ovo M/O 1g 13A DP Swt Skt PB/BL
Height

88.0mm
Width

88.0mm
Depth

13.5mm
