Verve White 1g 10AX Inter Mini Gd Rkr WH

SKU: HM2027 Category:
Verve White 1g 10AX Inter Mini Gd Rkr WH
Verve White 1g 10AX Inter Mini Gd Rkr WH - Image 2
SKU: HM2027 Category:

Type

1 gang Mini Grid Fix10AX Intermediate Rocker

Plate Finish

White

Insert Finish

White

Description

White 10AX 1G Intermediate Mini Grid Rocker Switch White

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Verve
Page-Sort-Order

050-001-121
Insert-Type

1 gang Mini Grid Fix10AX Intermediate Rocker
Insert-Colour

White
Uf-ItmLabelTechInsert

VER-R31
Uf-HAM-Plate-Range

Verve Box Fix
Uf-HAMPlate-Generic-Size

Single
Range-Name

Verve
Item-Long-Description

White 10AX 1G Intermediate Mini Grid Rocker Switch White
PlateFinish

Verve Box Fix White
EAN13-Barcode

5052750550163
Dimensions(Nominal)

Single: Height = 86.7mm Width = 86.7mm Depth = 10.0mm
Commodity-Code

85365080
Dimension-Image

Luckins-TSI

434147775
Tech-Sheet-Page-Footer

HM2027 – White 10AX 1G Intermediate Mini Grid Rocker Switch White
product-code

S TRD-VVBX
family-code

S TRD VERV
last-inv

25/02/26
unit-weight

72.00000
weight-units

GR
Uf-ItmLabelCE

Uf-LuckinsEDP

4533420535
Uf-HAMInnerBoxQty

10
Uf-OuterBoxQty

100
Picture-Exists

Yes
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

050
HAM-SortOrder

001
InsertSortOrder

121
Generic-Size

Single
Box-Fixing-Hole-Centres

60.3mm
Grid-Fixing-Hole-Centres

N/A
Uf-HAMPlateFinish

White
Uf-HAMFrameFinish

n/a
WEB-InsertType

Intermediate
WEB-NumberofGangs

1
MainInsertColour

White
TrimColour

n/a
Last-Updated-At-Hamilton

25/02/26
Switched-Poles

Single
Current-Rating

10AX
Maximum-Load

10 Amp inductive
Contact-Gap-Minimum

3mm
Terminal-Capacity-1

5x1mm²
Terminal-Capacity-2

4×1.5mm²
Terminal-Capacity-3

1×2.5mm²
Terminal-Capacity-4

1x4mm²
Earth-Terminal-Capacity-1

5x1mm²
Earth-Terminal-Capacity-2

4×1.5mm²
Earth-Terminal-Capacity-3

3×2.5mm²
Earth-Terminal-Capacity-4

1 x 4mm2
Product-Class-1

Must be earthed
Ambient-Operating-Temperatur

-5° to +40°C
Recommended-Location

Internal Use Only
Maximum-Installation-Altitud

2000m
Standard-Approval

BS EN 60669-1
Item-Image

Fixing-Hole-Centres

Box Fixing = 60.3mm Grid Fixing = N/A
Minimum-Wall-Box-Depth

25mm
Plate-Finish

White
Subheader2

Verve Range
QR-Instruction

https://online.fliphtml5.com/Hamilton/bfnc/#p=1
Weight

72 GR
Voltage

220/250V AC
IP-Rating

IP20
description

Verve White 1g 10AX Inter Mini Gd Rkr WH
Height

86.7mm
Width

86.7mm
Depth

10.0mm

Download datasheet
