Verve White Shaver Dual Volt Socket WH

SKU: HM2090 Category:
Verve White Shaver Dual Volt Socket WH
Verve White Shaver Dual Volt Socket WH - Image 2
SKU: HM2090 Category:

Type

Shaver Dual Voltage Unswitched Socket (Vertically Mounted)

Plate Finish

White

Insert Finish

White

Description

White Dual Voltage Shaver Socket

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Verve
Page-Sort-Order

050-021-111
Insert-Type

Shaver Dual Voltage Unswitched Socket (Vertically Mounted)
Insert-Colour

White
Uf-ItmLabelTechInsert

VER-SHS
Uf-HAM-Plate-Range

Verve Box Fix
Uf-HAMPlate-Generic-Size

Double
Range-Name

Verve
Item-Long-Description

White Dual Voltage Shaver Socket
PlateFinish

Verve Box Fix White
EAN13-Barcode

5052750550491
Dimensions(Nominal)

Double: Height = 86.7mm Width = 146.5mm Depth = 10.0mm
Commodity-Code

85366990
Dimension-Image

Luckins-TSI

434148004
Tech-Sheet-Page-Footer

HM2090 – White Dual Voltage Shaver Socket
product-code

S TRD-VVBX
family-code

S TRD VERV
last-inv

25/02/26
unit-weight

610.00000
weight-units

GR
Uf-ItmLabelCE

Uf-LuckinsEDP

4533420768
Uf-HAMInnerBoxQty

1
Uf-OuterBoxQty

16
Picture-Exists

Yes
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

050
HAM-SortOrder

021
InsertSortOrder

111
Generic-Size

Double
Box-Fixing-Hole-Centres

120.6mm
Grid-Fixing-Hole-Centres

N/A
Uf-HAMPlateFinish

White
Uf-HAMFrameFinish

n/a
WEB-InsertType

Shaver Socket
WEB-NumberofGangs

1
MainInsertColour

White
TrimColour

n/a
Last-Updated-At-Hamilton

25/02/26
Switched-Poles

None
Current-Rating

20VA
Maximum-Load

220/250V input; 115/230V 20VA output
Contact-Gap-Minimum

None
Terminal-Capacity-1

5 x1mm²
Terminal-Capacity-2

4×1.5mm²
Terminal-Capacity-3

3×2.5mm²
Terminal-Capacity-4

2x4mm² Multi-strand
Terminal-Capacity-5

1x6mm²
Earth-Terminal-Capacity-1

9x1mm²
Earth-Terminal-Capacity-2

6×1.5mm²
Earth-Terminal-Capacity-3

4×2.5mm²
Earth-Terminal-Capacity-4

2 x 4mm²
Earth-Terminal-Capacity-5

1x6mm²
Product-Class-1

Must be earthed
Ambient-Operating-Temperatur

-5° to +40°C
Recommended-Location

Internal Use Only
Maximum-Installation-Altitud

2000m
Standard-Approval

BS EN 61558-2-5 + BS 4573
Item-Image

Fixing-Hole-Centres

Box Fixing = 120.6mm Grid Fixing = N/A
Minimum-Wall-Box-Depth

47mm
Plate-Finish

White
Subheader2

Verve Range
QR-Instruction

https://online.fliphtml5.com/Hamilton/bzky/#p=1
Weight

610 GR
Voltage

220/250V AC
IP-Rating

IP20
description

Verve White Shaver Dual Volt Socket WH
Height

86.7mm
Width

146.5mm
Depth

10.0mm
