Verve White 150×150 6 Gang Grid Plate

SKU: HM2066 Category:
Verve White 150x150 6 Gang Grid Plate
Verve White 150x150 6 Gang Grid Plate - Image 2
SKU: HM2066 Category:

Type

6 gang Grid Fix Aperture Plate with Grid

Plate Finish

White

Insert Finish

N/A

Description

Verve 150×150 6 gang grid plate frame White

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Verve
Page-Sort-Order

050-042-111
Subheader2

Verve Grid-It
Insert-Type

6 gang Grid Fix Aperture Plate with Grid
Plate-Finish

White
Insert-Colour

N/A
Uf-ItmLabelTechInsert

VER-6GP
Uf-HAM-Plate-Range

Verve Micro Grid
Uf-HAMPlate-Generic-Size

Double
Range-Name

Verve
Item-Long-Description

Verve 150×150 6 gang grid plate frame White
PlateFinish

Verve Micro Grid White
EAN13-Barcode

5052750502520
Dimensions(Nominal)

Double: Height = 86.7mm Width = 145.5mm Depth = 10.0mm
Weight

160 GR
Fixing-Hole-Centres

Box Fixing = 120.6mm Grid Fixing = N/A
Minimum-Wall-Box-Depth

As Per Inserts
Switched-Poles

N/A
Current-Rating

n/a
Voltage

Insert Specific
IP-Rating

IP20
Earth-Terminal-Capacity-1

5x1mm²
Earth-Terminal-Capacity-2

4 x 1.5mm2
Earth-Terminal-Capacity-3

3 x 2.5mm2
Earth-Terminal-Capacity-4

1 x 4mm2
Product-Class-1

Must be earthed
Ambient-Operating-Temperatur

-5° to +40°C
Recommended-Location

Internal Use Only
Maximum-Installation-Altitud

2000m
Standard-Approval

N/A
Commodity-Code

39091000
Wiring-Image

Dimension-Image

Tech-Sheet-Page-Footer

HM2066 – Verve 150×150 6 gang grid plate frame White
description

Verve White 150×150 6 Gang Grid Plate
product-code

S TRD-VVMG
family-code

S TRD VERV
unit-weight

160.00000
weight-units

GR
Uf-HAMInnerBoxQty

10
Uf-OuterBoxQty

100
Picture-Exists

No
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

50
HAM-SortOrder

42
InsertSortOrder

111
Generic-Size

Double
Height

86.7mm
Width

145.5mm
Depth

10.0mm
Box-Fixing-Hole-Centres

120.6mm
Grid-Fixing-Hole-Centres

N/A
Uf-HAMPlateFinish

White
Uf-HAMFrameFinish

n/a
WEB-InsertType

Plate
WEB-NumberofGangs

6
MainInsertColour

N
TrimColour

A
Last-Updated-At-Hamilton

01/05/2026
