Vv Wh Mcr Gd 1g 20AX DP Fan Symbol-Lg

SKU: HM3116FN Category:
Vv Wh Mcr Gd 1g 20AX DP Fan Symbol-Lg
Vv Wh Mcr Gd 1g 20AX DP Fan Symbol-Lg - Image 2
SKU: HM3116FN Category:

Type

1 gang 20AX Double Pole Rocker (Large Switch) + Printed Legend

Plate Finish

N/A

Insert Finish

White

Description

Micro Grid 1G 20A Double Pole (2G Size) Rocker Fan Symbol White

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Verve
Page-Sort-Order

050-027-
Insert-Type

1 gang 20AX Double Pole Rocker (Large Switch) + Printed Legend
Insert-Colour

White
Uf-ItmLabelTechInsert

VER-MGDP-DBL-PR
Uf-HAM-Plate-Range

Verve Micro Grid
Uf-HAMPlate-Generic-Size

Module
Range-Name

Verve
Item-Long-Description

Micro Grid 1G 20A Double Pole (2G Size) Rocker Fan Symbol White
PlateFinish

Verve Micro Grid N/A
EAN13-Barcode

5052750551030
Dimensions(Nominal)

Module: Height = Width = Depth =
Commodity-Code

85365080
Dimension-Image

Luckins-TSI

434148567
Tech-Sheet-Page-Footer

HM3116FN – Micro Grid 1G 20A Double Pole (2G Size) Rocker Fan Symbol White
product-code

S TRD-VVMG
family-code

S TRD VERV
last-inv

28/06/2024
unit-weight

33.00000
weight-units

GR
Uf-ItmLabelCE

Uf-LuckinsEDP

4533421327
Uf-HAMInnerBoxQty

50
Uf-OuterBoxQty

500
Picture-Exists

Yes
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

50
HAM-SortOrder

27
Generic-Size

Module
Uf-HAMPlateFinish

White
Uf-HAMFrameFinish

n/a
WEB-InsertType

Double Pole
WEB-NumberofGangs

1
MainInsertColour

White
TrimColour

n/a
Last-Updated-At-Hamilton

03/02/2026
Switched-Poles

Double
Current-Rating

20AX
Earth-Terminal-Capacity-1

5x1mm²
Earth-Terminal-Capacity-2

4×1.5mm²
Earth-Terminal-Capacity-3

3×2.5mm²
Earth-Terminal-Capacity-4

1x4mm²
Product-Class-1

Must be earthed
Ambient-Operating-Temperatur

-5° to +40°C
Recommended-Location

Internal Use Only
Maximum-Installation-Altitud

2000m
Standard-Approval

BS EN 60669-1
Item-Image

Minimum-Wall-Box-Depth

25mm
Plate-Finish

N/A
Subheader2

Verve Double Pole Switches
QR-Instruction

https://online.fliphtml5.com/Hamilton/efun/#p=1
Weight

33 GR
IP-Rating

IP20
description

Vv Wh Mcr Gd 1g 20AX DP Fan Symbol-Lg
