Verve White 50A DP+NEON VERT Rkr WH

SKU: HM2053 Category:
Verve White 50A DP+NEON VERT Rkr WH
Verve White 50A DP+NEON VERT Rkr WH - Image 2
SKU: HM2053 Category:

Type

1 gang 50A Double Pole Rocker and Neon (Vertically Mounted)

Plate Finish

White

Insert Finish

White

Description

White 50A 2G Vertical + Red Neon Double Pole Rocker White

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Verve
Page-Sort-Order

050-027-125
Insert-Type

1 gang 50A Double Pole Rocker and Neon (Vertically Mounted)
Insert-Colour

White
Uf-ItmLabelTechInsert

VER-50NV
Uf-HAM-Plate-Range

Verve Box Fix
Uf-HAMPlate-Generic-Size

Double
Range-Name

Verve
Item-Long-Description

White 50A 2G Vertical + Red Neon Double Pole Rocker White
PlateFinish

Verve Box Fix White
EAN13-Barcode

5052750550330
Dimensions(Nominal)

Double: Height = 86.7mm Width = 146.5mm Depth = 10.0mm
Commodity-Code

85365080
Dimension-Image

Luckins-TSI

434148279
Tech-Sheet-Page-Footer

HM2053 – White 50A 2G Vertical + Red Neon Double Pole Rocker White
product-code

S TRD-VVBX
family-code

S TRD VERV
last-inv

18/12/2025
unit-weight

173.00000
weight-units

GR
Uf-ItmLabelCE

Uf-LuckinsEDP

4533421039
Uf-HAMInnerBoxQty

5
Uf-OuterBoxQty

50
Picture-Exists

Yes
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

50
HAM-SortOrder

27
InsertSortOrder

125
Generic-Size

Double
Box-Fixing-Hole-Centres

120.6mm
Grid-Fixing-Hole-Centres

N/A
Uf-HAMPlateFinish

White
Uf-HAMFrameFinish

n/a
WEB-InsertType

Double Pole
WEB-NumberofGangs

1
MainInsertColour

White
TrimColour

n/a
Last-Updated-At-Hamilton

31/12/2025
Switched-Poles

Double
Current-Rating

50 Amp
Maximum-Load

50 Amp
Contact-Gap-Minimum

3mm
Terminal-Capacity-1

3x6mm²
Terminal-Capacity-2

1x10mm²
Terminal-Capacity-3

1x16mm²
Earth-Terminal-Capacity-1

3x6mm²
Earth-Terminal-Capacity-2

1 x 10mm²
Earth-Terminal-Capacity-3

1 x 16mm2
Product-Class-1

Must be earthed
Ambient-Operating-Temperatur

-5° to +40°C
Recommended-Location

Internal Use Only
Maximum-Installation-Altitud

2000m
Standard-Approval

BS EN 60669-1
Item-Image

Fixing-Hole-Centres

Box Fixing = 120.6mm Grid Fixing = N/A
Minimum-Wall-Box-Depth

35mm
Plate-Finish

White
Subheader2

Verve Double Pole Switches
QR-Instruction

https://online.fliphtml5.com/Hamilton/efun/#p=1
Weight

173 GR
Voltage

220/250V AC
IP-Rating

IP20
description

Verve White 50A DP+NEON VERT Rkr WH
Height

86.7mm
Width

146.5mm
Depth

10.0mm

Download datasheet
