Verve White 13A DP Fuse SP+CO+N WH

SKU: HM2076 Category:
Verve White 13A DP Fuse SP+CO+N WH
Verve White 13A DP Fuse SP+CO+N WH - Image 2
SKU: HM2076 Category:

Type

1 gang 13A Double Pole Fused Spur and Neon and Cable Outlet

Plate Finish

White

Insert Finish

White

Description

White 13A Double Pole Switched Spur + Flex Outlet + Red Neon White

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Verve
Page-Sort-Order

050-026-103
Insert-Type

1 gang 13A Double Pole Fused Spur and Neon and Cable Outlet
Insert-Colour

White
Uf-ItmLabelTechInsert

VER-SPNC
Uf-HAM-Plate-Range

Verve Box Fix
Uf-HAMPlate-Generic-Size

Single
Range-Name

Verve
Item-Long-Description

White 13A Double Pole Switched Spur + Flex Outlet + Red Neon White
PlateFinish

Verve Box Fix White
EAN13-Barcode

5052750550422
Dimensions(Nominal)

Single: Height = 86.7mm Width = 86.7mm Depth = 10.0mm
Commodity-Code

85363010
Dimension-Image

Luckins-TSI

434147940
Tech-Sheet-Page-Footer

HM2076 – White 13A Double Pole Switched Spur + Flex Outlet + Red Neon White
product-code

S TRD-VVBX
family-code

S TRD VERV
last-inv

07/09/2025
unit-weight

115.00000
weight-units

GR
Uf-ItmLabelCE

Uf-LuckinsEDP

4533420700
Uf-HAMInnerBoxQty

10
Uf-OuterBoxQty

100
Picture-Exists

Yes
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

50
HAM-SortOrder

26
InsertSortOrder

103
Generic-Size

Single
Box-Fixing-Hole-Centres

60.3mm
Grid-Fixing-Hole-Centres

N/A
Cable-Outlet-Min

0.75mm²
Cable-Outlet-Max

2.5mm²
Uf-HAMPlateFinish

White
Uf-HAMFrameFinish

n/a
WEB-InsertType

Double Pole
WEB-NumberofGangs

1
MainInsertColour

White
TrimColour

n/a
Last-Updated-At-Hamilton

31/12/2025
Switched-Poles

Single
Current-Rating

13 Amp
Maximum-Load

13 Amp
Contact-Gap-Minimum

3mm
Terminal-Capacity-1

3×2.5mm²
Terminal-Capacity-2

2x4mm² Multi-Strand
Terminal-Capacity-3

1x6mm²
Terminal-Capacity-4

6x1mm²
Earth-Terminal-Capacity-1

5×1.5mm²
Earth-Terminal-Capacity-2

3×2.5mm²
Earth-Terminal-Capacity-3

2x4mm²
Earth-Terminal-Capacity-4

1x6mm²
Product-Class-1

Must be earthed
Ambient-Operating-Temperatur

-5° to +40°C
Recommended-Location

Internal Use Only
Maximum-Installation-Altitud

2000m
Cable-Outlet-Minimum-Maximum

Min = 0.75mm² Max = 2.5mm²
Standard-Approval

BS 1363-4
Item-Image

Fixing-Hole-Centres

Box Fixing = 60.3mm Grid Fixing = N/A
Minimum-Wall-Box-Depth

35mm
Plate-Finish

White
Subheader2

Verve Connection Units
QR-Instruction

https://online.fliphtml5.com/Hamilton/jfee/#p=1
Weight

115 GR
Voltage

220/250V AC
IP-Rating

IP20
description

Verve White 13A DP Fuse SP+CO+N WH
Height

86.7mm
Width

86.7mm
Depth

10.0mm
