Shr G2 MB 4g 20AX 2Way Toggle MB

Shr G2 MB 4g 20AX 2Way Toggle MB
Shr G2 MB 4g 20AX 2Way Toggle MB - Image 2

Type

4 gang 20AX 2 Way FL Dolly

Plate Finish

Matt Black

Insert Finish

Matt Black

Description

Hartland G2 Matt Black 4 gang 20AX 2 Way Toggle Matt Black

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Hartland G2
Page-Sort-Order

011-016-004
Subheader2

Hartland G2 Dollies
Insert-Type

4 gang 20AX 2 Way FL Dolly
Plate-Finish

Matt Black
Insert-Colour

Matt Black
QR-Instruction

https://online.fliphtml5.com/Hamilton/uzsv/#p=1
Uf-ItmLabelTechInsert

T24-FLDLY
Uf-HAM-Plate-Range

Sheer G2
Uf-HAMPlate-Generic-Size

Double
Range-Name

Hartland G2
Patents-And-Trade-Marks

Hartland G2 is a Registered Trade Mark No UK00003388376
Item-Long-Description

Hartland G2 Matt Black 4 gang 20AX 2 Way Toggle Matt Black
PlateFinish

Sheer G2 Matt Black
EAN13-Barcode

5017503009855
Dimensions(Nominal)

Double: Height = 85mm Width = 144mm Depth = 1.5mm + 2.7mm Gasket
Fixing-Hole-Centres

Box Fixing = 120.6mm Grid Fixing = CFX Clips
Minimum-Wall-Box-Depth

35mm
Current-Rating

20AX
Commodity-Code

85365080
Wiring-Image

Dimension-Image

Luckins-TSI

438794302
Tech-Sheet-Page-Footer

8G2MBT24 – Hartland G2 Matt Black 4 gang 20AX 2 Way Toggle Matt Black
description

Sheer G2 MB 4g 20AX 2Way Toggle MB
product-code

S HTG2 MB
family-code

S HART G2
last-inv

02/06/2026
unit-weight

0.00000
weight-units

GR
Uf-ItmLabelCE

Uf-LuckinsEDP

4533468225
Uf-HAMInnerBoxQty

3
Uf-OuterBoxQty

30
Picture-Exists

No
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

11
HAM-SortOrder

16
InsertSortOrder

004
Generic-Size

Double
Height

85mm
Width

144mm
Depth

1.5mm + 2.7mm Gasket
Box-Fixing-Hole-Centres

120.6mm
Grid-Fixing-Hole-Centres

CFX Clips
Module-Size-Height

53mm
Module-Size-Depth

23mm
Uf-HAMPlateFinish

Matt Black
Uf-HAMFrameFinish

n/a
WEB-InsertType

2 Way
WEB-NumberofGangs

4
MainInsertColour

Matt Black
TrimColour

n/a
Last-Updated-At-Hamilton

03/02/2026

Download datasheet
