Super Stockists

Cher V AB DP SS2 + USBULTx2 AB/BL

SKU: 93SS2USBULTABB Category:
Awaiting product image
SKU: 93SS2USBULTABB Category:

Type

2 gang 13A Double Pole Switched Socket with 2 USB Outlets 2x2.4A (4.8A Total)

Plate Finish

Antique Brass

Insert Finish

Antique Brass/Black

Description

Cheriton Victorian Antique Brass 2 gang 13A Double Pole Switched Socket with 2 USB Ultra Outlets 2×2.4A Antique Brass/Black

Additional information

InsertColourTitle

Insert Finish/Surround Colour
Section-Name

Cheriton Victorian
Page-Sort-Order

023-023-001
Insert-Type

2 gang 13A Double Pole Switched Socket with 2 USB Outlets 2×2.4A (4.8A Total)
Insert-Colour

Antique Brass/Black
Uf-ItmLabelTechInsert

SS2USBX2ULT
Uf-HAM-Plate-Range

Cheriton Victorian Box
Uf-HAMPlate-Generic-Size

Double
Range-Name

Cheriton Victorian
Patents-And-Trade-Marks

Cheriton is a Registered Trade Mark No. 2344779
Item-Long-Description

Cheriton Victorian Antique Brass 2 gang 13A Double Pole Switched Socket with 2 USB Ultra Outlets 2×2.4A Antique Brass/Black
PlateFinish

Cheriton Victorian Box Antique Brass
EAN13-Barcode

5017504094195
Dimensions(Nominal)

Double: Height = 86.5mm Width = 146.0mm Depth = 7.5mm
Fixing-Hole-Centres

Box Fixing = 120.6mm Grid Fixing = N/A
Minimum-Wall-Box-Depth

35mm
Switched-Poles

Double
Current-Rating

13 Amp, USB 2 x 2.4A
Voltage

180/250V AC USB = 5V
Maximum-Load

13 Amp, USB = 2.4A X 2
Mains-Frequency

50/60Hz
IP-Rating

IP2XD
Contact-Gap-Minimum

3mm
Terminal-Capacity-1

3×2.5mm²
Terminal-Capacity-2

3x4mm²
Terminal-Capacity-3

2x6mm² Multi-Strand
Earth-Terminal-Capacity-1

3×2.5mm²
Earth-Terminal-Capacity-2

3x4mm²
Earth-Terminal-Capacity-3

2x6mm² Multi-Strand
Product-Class-1

Must be earthed
Ambient-Operating-Temperatur

-15°C to +40°C
Recommended-Location

Internal Use Only
Maximum-Installation-Altitud

2000m
Standard-Approval

BS1363 BS EN 62368
Commodity-Code

85366990
Wiring-Image

Dimension-Image

Luckins-TSI

433710569
Tech-Sheet-Page-Footer

93SS2USBULTAB-B – Cheriton Victorian Antique Brass 2 gang 13A Double Pole Switched Socket with 2 USB Ultra Outlets 2×2.4A Antique Brass/Black
description

Cher V AB DP SS2 + USBULTx2 AB/BL
product-code

S CHER VAB
family-code

S CHER VIC
last-inv

25/07/2025
unit-weight

0.00000
weight-units

GR
Uf-LuckinsEDP

4533417386
Uf-HAMInnerBoxQty

5
Uf-OuterBoxQty

20
Picture-Exists

No
Uf-ITMTechDataType

Plate
Uf-IncludeinPriceList

Yes
FamilySortOrder

23
HAM-SortOrder

23
InsertSortOrder

001
Generic-Size

Double
Height

86.5mm
Width

146.0mm
Depth

7.5mm
Box-Fixing-Hole-Centres

120.6mm
Grid-Fixing-Hole-Centres

N/A
Uf-HAMPlateFinish

Antique Brass
Uf-HAMFrameFinish

n/a
WEB-InsertType

Double Pole
WEB-NumberofGangs

2
MainInsertColour

Antique Brass
TrimColour

Black
Last-Updated-At-Hamilton

23/01/2026
Plate-Finish

Antique Brass
Subheader2

Cheriton Victorian USB Power Sockets
QR-Instruction

https://online.fliphtml5.com/Hamilton/dcop/#p=1

Download datasheet
